Siddhivinayak Automation



Business Type Manufacturer, Exporter, Supplier, Retailer, Wholesaler
Sleeve Labe Roll Empty Machine stop with Alarm.
Missing Sleeve Label Machine stop with alarm or online pneumatic operated product rejection system.
Tower Light Indicate the status of process.
Click to view more

Preferred Buyer From

Location Anywhere in India

Product Details

Model
SVSSA 100, SVSSA 200 , SVSSA 300
Output/Min*
Up to 100, Up to 200, Up to 300
Container Size
ø28mm – ø125mm, 320mm Height Max.
Length of sleeve
30mm – 250mm
Thickness of Sleeve
0.035mm – 0.75mm
Label Material
PVC, PET, OPS, PLA
Sleeve Roll Inner Dia.
>4” (101.6mm)
Sleeve Roll Outer Dia.
400mm
Height of Conveyor
860-910mm
Electrical Rating
1.5KW-2KW, 380V AC, 50/60HZ, 3-Phase
Change Parts
(A) Center Pillar (B) Worm © Cutter

Silent Features :

  • Rigid Structure constructed S.S. and anodizing aluminum alloy.
  • Fully automatic machine with speed up to 300 BPM.
  • No bottle no sleeve.
  • Statics Charges elimination system for accurate sleeve placement.
  • Totally PLC Control system.
  • No Tools required for changeovers from one size bottle to another.
  • Servo based high speed with accurate length sleeve feeding and rotary sleeve cutter system.
  • Online speed can vary & fully synchronized with all mechanism.
  • Suitable for various shape of Glass, Plastic, Pet, Tin, Corrugated Containers.
  • Online Printer
